Exit Device
SKU BC40010
- Features - This device is reversible to work on both left- or right-handed doors. Can be adjusted with a dogging device to be constantly open.
- Measurements - Fits doors 28” to 42” wide and comes with a deadlocking latch bolt with 5/8” projection.
- Exit device meets ADA and ANSI Grade 1 standards, and is UL305 compliant.
- Installation - This exit device includes everything needed to install and use, including the SC4 brass rim cylinder and a small steel pull plate.
- Quality You Can Trust - A global leader in security-related products and services, the Brink's name is synonymous with top quality products to keep you and your belongings safe.
Product Description
This device is reversible to work on both left- or right-handed doors. Can be adjusted with a dogging device to be constantly open. Fits doors 28” to 42” wide and comes with a deadlocking latch bolt with 5/8” projection. Meets ANSI Grade 1 standards is UL 305 Compliant and meets ADA requirements with the lever trim. This exit device includes everything needed to install and use, including the SC4 brass rim cylinder and a small steel pull plate. A global leader in security-related products and services, the Brink's name is synonymous with top quality products to keep you and your belongings safe.
Construction
- Steel construction that's ideal for heavy-use
- Satin aluminum finish pairs well in all settings and decors
- Limited 10 year warranty covers finish and function
- UL 305 Compliant: Designed to facilitate the egress of persons from buildings in the event of panic or other emergency
- ADA Compliant: Meets ADA requirements, ensuring accessibility to all disabled persons
Durability
- Included SC4 Brass Cylinder for added security and pull plate for added convenience
- Meets ANSI Grade 1 Standards
- Device is tested to exceed 500,000 cycles (ANSI Grade 1)
Installation
- Deadlocking latch bolt with 5/8" projection
- Ideal for doors with 2 3/4" backset optional shim included for doors with greater than 2 3/4" backset.
- Included SC4 Brass Cylinder and pull plate for added security
- Non-Handed: Can be applied to left or right handed doors
- Dogging: Latch can be dogged in open position for high-traffic doors
- Ideal for doors up to 36"-42" wide and can be field-sized to work with 28" doors.
Videos
Product Information
Item Details
- Category
- Exit Devices
- Function
- Push
- Color
- Aluminum
- Mount Type
- Surface Mount
- Interior Door Compatibility
- Intended for doors 36" to 42" wide. Can be field-sized to work with doors down to 28" wide
- Mount Type
- Surface Mount
- Warranty
- 10 Year Limited Warranty
- UPC
- 039208237178
